GM-Series 208V-480V Generator Output & Fire Pump Protection Distribution Panel

Generator Set Mountable Output Distribution Circuit Breaker(s) with Optional Segregated Fire Pump Circuit Breaker Panel

Home » Power System Products » Low Voltage Switchboards & Switchgear » GM-Series Generator Output & Fire Pump Protection Distribution Panel
Advanced-Power-Technologies-APT-Lafayette-Indiana-Web-Logo
Sidebar-Contact-Us-APT-Power

Site Map

Logo-APTView-Enabled-APT-Power

Total:

   MCCB Information

APT GM-Series Generator Output & Fire Pump Protection Distribution Panel is a generator mountable molded case circuit breaker panel that allows single or multiple circuit breakers to be mounted onto a gen-set to feed output loads up to 3000A.

   Gen-Mount Panel

  • Application Voltage:
    o 120V/240V (2Ø)
    o 120V/208V, 480V, 600V (3Ø)
  • NEMA standard hole pattern (3000A) or circuit
    breaker lug terminations for connections.
  • Enclosure
    o NEMA 1 (indoor) or NEMA 3R (outdoor)
    o Carbon steel.
    o Painted ANSI 61 Gray or a variety of
    custom colors.
    o Screw Removable Front Panel allows
    circuit breaker bus and lug access.
    o Your choice of cable entrance/exit
    locations
    o Typical Dimensions:
    § 40″H x 28”W x 18”D

   MCCB

    • 20” Color touch-screen
    • Microsoft Windows
    • APT industrial computer (AiPC) equipped with the powerful APTView Control & Monitoring Software
    • Provides SCADA graphical user interface (GUI) for control and monitoring of the MMCP functions
    • Allows MMCP functions to provide the following:
      • Microgrid System One Line
      • Storage of all the monitored data every minute with date and time stamp
      • Emails can be sent upon any triggered event condition
      • Free license remote monitoring and remote-control software
      • Capability of remote system troubleshooting
      • Adjustable setpoints and modes of operation to allow user to adopt the system operation to changing needs.

       Floor-Standing Panel

    • Floor-Standing/Pad Mountable
    • Large Bus Bar Connections Simplify Field Cable Installation
    • Provides Robust 100% Rated Disconnecting Mans, with Short Circuit and Overload Protection
    • Carbon Steel Enclosure powder coated ANSI 61 Gray
    • Enclosure Includes Hinged Front Door with Lockable T-Handles
    • Dimensions: 80”H x 28”W x (23” up to 62”D)
    • Options:
      • UL  Listed
      • Service Entrance Rated
      • LSI, LSIG
      • Electric Operator
      • Draw Out Circuit Breaker
      • Circuit Breaker Control Switch
      • Circuit Breaker Position Indicating Lamps
      • Electric Metering
      • Emergency Stop Pushbutton
      • Generator Protection
      • Fault Annunciation
      • Automatic Source Transfer Control
      • Generator Paralleling Control
      • Main Bus
      • Modbus Serial or Ethernet Communications
      • Aluminum or Stainless Steel Enclosure

    Product Literature

    Engineering Bid Specifications

    Installation Drawings & Diagrams

    Coming Soon!

    Applicable Standards

    NEMA-Logo-APT-Power
    IEEE-Logo-APT-Power
    APT-UL-508-508A-APT-Power2
    APT-UL-Logo-APT-Power-min
    APT-UL-891-APT-Power-2
    ANSI-Logo-APT-Power
    NFPA-Logo-2020-APT-Power
    NETA-Logo-APT-Power
    IEC-Logo-APT-Power
